3RP series lobe pumps are applied to handle suspensions, corrosive media, and liquid media containing soft solid particles with viscosities ranging from 30 cSt to 100,000 cSt. By utilizing positive displacement, this product offers significant advantages over traditional centrifugal pumps when handling high-viscosity liquids, foaming media, and materials that require the integrity of the raw material to be preserved. Moreover, to minimize wear and failures caused by direct contact, the product maintains precise and extremely small clearances between the cams and between the cams and the pump housing, thereby ensuring long-term, stable operation of the equipment.
Product Details:
After the 3RP series rotary lobe pump is started, the two rotors are driven by a synchronous gear to rotate in opposite directions in sync. The expanding volume of the pump chamber created by the rotating rotors generates a vacuum, drawing the fluid into the pump. With continued rotation, the fluid inside the pump chamber is carried toward the discharge port in the direction of the rotors’ movement. As the rotors continue to rotate, the volume of the pump chamber gradually decreases, forcing the fluid out through the discharge port at a steady rate, achieving a continuous flow.
.jpg)
Application:
1. In the food processing industry, it can be used to convey jam, honey, syrup, dairy products, chocolate slurry, and various food concentrates, ensuring material quality and production efficiency.
2. In the pharmaceutical and biotechnology sectors, it is suitable for pumping pharmaceutical solutions, nutrient solutions, emulsions, and other media with high hygiene requirements.
3. 3RP rotary pump handles beverage ingredient transfer, filling systems, and the transfer of high-viscosity liquids in the beverage industry to ensure a stable and continuous supply.
4. In the chemical industry, it is used to handle resins, coatings, adhesives, polymers, and various high-viscosity chemical liquids.
Feature:
1. It is inherently low-shear, allowing them to gently handle media containing particles, fibers, or high-value components while preventing structural changes in the material caused by high-speed agitation, making them ideal for production environments with stringent product quality requirements.
2. 3RP series lobe pumps feature a dual-rotor synchronous rotation design that generates minimal friction during operation, effectively reducing mechanical wear, improving operational efficiency, and extending the service life of core components.
3. This machine maintains stable performance during prolonged continuous operation, reducing the frequency of equipment downtime for maintenance and creating greater production value for users.
