As a positive-displacement pump specifically designed for conveying lubricating fluids, the YCB series gear pump has become the equipment of choice in industries such as coatings, building materials, petroleum, chemicals, machinery manufacturing, and food processing, thanks to its advanced curved design and highly efficient, stable performance. The product features an optimized gear structure, enhancing the precision of gear meshing to not only improve fluid delivery efficiency but also ensure a smoother operation with lower noise levels.
Product Details:
During operation of the YCB gear pump, the drive gear rotates the driven gear in sync via the drive mechanism as the gears rotate. As the gears gradually disengage at the suction inlet, the space between them continuously increases, creating a local vacuum that draws fluid into the pump chamber under the influence of the pressure differential. Through the rotation of the gears, the fluid is continuously conveyed along the pump body to the discharge port, causing the sealing space on that side to gradually decrease. The fluid is then compressed and discharged at a stable pressure, thereby achieving continuous and uniform fluid delivery.
.png)
Application:
YCB series gear pumps are particularly ideal for pumping media that contain no solid particles, are non-corrosive or slightly corrosive, and possess lubricating properties, such as diesel, heavy oil, lubricating oil, hydraulic oil, fuel oil, heat transfer oil, and other liquids with similar properties. For the pumping of high-viscosity media, this series minimizes shear stress and energy loss while ensuring a stable flow rate. Whether in the petroleum, chemical, machinery manufacturing, or building materials industries, it excels at meeting production-related pumping requirements.
Feature:
1. This product series offers excellent wear resistance and a long service life, maintaining stable flow delivery even under conditions of prolonged continuous operation.
2. Its key components are made of high-quality materials, and the sealing materials can be selected based on specific operating conditions, ensuring leak-free delivery during operation.
3. The design of its arc-toothed gears creates a continuous, stable sealed chamber during operation, reducing pressure fluctuations while significantly lowering operating noise and flow pulsations.
Performance Data:
| Model |
Flow
(m³/h) |
Pressure
(Mpa) |
Rev
(rpm) |
Npshr
(m) |
Frequency
(hz) |
| YCB0.6-0.6 |
0.6
1.0
0.7
1.2 |
0.6 |
910
1390
1130
1710 |
5.5 |
50
50
60
60 |
| YCB0.6-1.6 |
0.6
1.0
0.7
1.2 |
1.6 |
910
1400
1130
1710 |
7.0 |
50
50
60
60 |
| YCB1.6-0.6 |
1.6
2.5
1.9
3.0 |
0.6 |
910
1400
1130
1710 |
5.5 |
50
50
60
60 |
| YCB1.6-1.6 |
1.6
2.5
1.9
3.0 |
1.6 |
940
1440
1150
1750 |
7.0 |
50
50
60
60 |
| YCB3.3-0.6 |
3.3
5.0
4.0
6.0 |
0.6 |
940
1420
1150
1730 |
5.0 |
50
50
60
60 |
| YCB3.3-1.6 |
3.3
5.0
4.0
6.0 |
1.6 |
960
1440
1170
1750 |
7.0 |
50
50
60
60 |
| YCB4-0.6 |
4.0
6.0
4.8
7.2 |
0.6 |
940
1420
1150
1730
|
5.0 |
50
50
60
60 |
| YCB4-1.6 |
4.0
6.0
4.8
7.2 |
1.6 |
960
1440
1170
1750 |
7.0 |
50
50
60
60 |
| YCB8-0.6 |
8.0
12.0
9.6
14.4 |
0.6 |
960
1440
1170
1750 |
5.0 |
50
50
60
60 |
| YCB8-1.6 |
8.0
12.0
9.6
14.4 |
1.6 |
970
1460
1170
1760 |
7.0 |
50
50
60
60 |
| YCB10-0.6 |
10.0
15.0
12.0
18.0 |
0.6 |
960
1440
1170
1750 |
5.0 |
50
50
60
60 |
| YCB10-1.6 |
10.0
15.0
12.0
18.0 |
1.6 |
970
1470
1170
1770 |
7.0 |
50
50
60
60 |
