WCB gear pumps incorporate specialized heat treatment technology and a precision gear meshing design, giving them excellent wear resistance and durability to effectively reduce equipment wear during operation and extend the service life of the entire unit, while also effectively minimizing pressure fluctuations during pumping and minimizing vibration and noise generated during the pumping process. Its portable design features a compact and well-engineered structure with a small footprint, rendering it uniquely tailored for use in production environments with limited space to meet the application requirements of various industrial sites.
Product Details:
In the WCB series gear pumps, when the motor drives the gears to rotate, the internal gears mesh with one another and turn. By gradually disengaging from one another, the gears form a sealed space, allowing the fluid to be drawn into the pump chamber under atmospheric pressure. While the gears continue to rotate, the fluid is compressed as the volume gradually decreases and is steadily discharged, accomplishing a continuous and stable delivery process.
Application:
WCB portable gear pumps facilitate the transfer of heavy oil, vegetable oil, lubricating oil, diesel, heat transfer oil, and other lubricating media, finding applications in fuel transfer, industrial manufacturing, agricultural machinery, petroleum refining, mining, metallurgy, and various industrial circulating lubrication systems. To accommodate use in the food or pharmaceutical industries, stainless steel materials can be selected based on the characteristics of the medium to meet sanitary production standards.
Feature:
1. The pump' s key components are made of wear-resistant materials, which effectively reduce wear and tear, extend the equipment’s service life, and ensure zero leakage during the conveying process.
2. This product features a high-precision gear meshing design, ensuring stable flow and minimal pulsation during conveyance, while effectively reducing noise and vibration during operation.
3. With its simple structure and few parts, maintenance and replacement operations are straightforward, helping users minimize equipment downtime.
4. It has portable design with a compact and well-engineered structure, making it suitable for use in environments with limited production space.
Performance Data:
| Type |
Flow
(L/min) |
Conveying Height
(m) |
Weight (kg) |
Power
(W) |
Power
(V) |
Material |
| WCB30 |
30 |
30 |
17 |
370 |
220 |
Csat iron |
| WCB50 |
50 |
30 |
19 |
550 |
220 |
Csat iron |
| WCB75 |
75 |
30 |
21 |
750 |
220 |
Csat iron |
| WCB30P |
30 |
30 |
17 |
370 |
220 |
Stainless steel |
| WCB50P |
50 |
30 |
19 |
550 |
220 |
Stainless steel |
| WCB75P |
75 |
30 |
21 |
750 |
220 |
Stainless steel |
