Product Description

Summarize:

3RP chemical rotary lobe pump is a rotary displacement pump that can transport suspensions, corrosive media and media with high hygiene requirements, and the temperature range of the transport medium is -30 to 180 °C. It is suitable for transporting suspensions with temperature -30 °C to 200 °C, viscosity 30 to 100000 mm2/s, solid particles, and media with high corrosive and hygiene requirements. Moreover, the internal parts of the pump in contact with the medium are made of durable stainless steel, which ensures the safety and hygiene of the medium to be conveyed.

Application:

3RP series chemical vane pump mainly composed of rotor, shaft seal, gear box, and a pair of synchronized meshing active gears to drive the rotor to convey the medium. It consists of two synchronized rotors/cams driven by a pair of synchronized gears in the gearbox. Under the drive of the main shaft and the secondary shaft, the two rotors rotate in opposite directions, thus changing the volume of the pump and increasing the vacuum and discharge pressure. In addition, the pump utilizes a high-strength cast iron gearbox, helical gears, and heavy-duty bearings to ensure long-term pump operation.

Application:

3RP series high viscosity lobe pump is often used for convey daily chemicals, including detergent, laundry detergent, shower gel, skin cream, shampoo, hand sanitizer, toothpaste, soap, washing powder slurry, daily chemical raw materials, etc.

Feature:

1. Optional flange type, screw type, clamp type and other types of connection methods.
2. High efficiency and energy saving, low failure rate, reliable sealing and low noise.
3. Built-in heat preservation and cooling structure, good thermal conductivity, easy to install.
4. It can transport materials with poor fluidity such as high viscosity and high concentration.
5. It can convey a wide range of gas, liquid and solid phase mixture materials and conveying materials.
6. It can be overhauled online, easy to assemble and disassemble, easy to maintain and clean, and less vulnerable parts.
7. Sanitary safety valve can be configured on the pump head, and the pipeline system pressure overload protection is simpler.
8. The output flow of the pump can be changed by adjusting the spindle speed, and it can be used as a general metering pump.
9. Keep a certain gap between the rotor and the rotor, the rotor and the pump body, no contact, no friction, and long service life.
10. After the rotor and pump cavity adopt special materials and processes, they can transport sludge, sewage and other media containing solid particles.

Performance Data:

Model	Flow		Discharge Pressure (Mpa)	Rev (rpm)	Motor Power (kw)	Inlet/Outlet (mm)
Model	L/100r	m3/h	Discharge Pressure (Mpa)	Rev (rpm)	Motor Power (kw)	Inlet/Outlet (mm)
3RP-25	6	≤1.8	0-1.0	10-400	0.75	25
3RP-32	9	≤2.7			1.1	32
3RP-40	18	≤4.3			1.5	40
3RP-50	36	≤8.6			2.2	50
3RP-65	60	≤14.4			4	65
3RP-80	105	≤25.2			11	80
3RP-100A	125	≤30			15	100
3RP-100	150	≤36			18.5	100
3RP-125	250	≤60			22	125
