Product Description

Summarize:

3RP high viscosity lobe pump is specifically designed for conveying suspensions containing solid particles and corrosive liquid media with viscosities ranging from 30 to 100,000 cst. With its low-shear and pulsation-free characteristics, this pump ensures stable delivery of honey, chocolate, meat paste, jam, and chemical substances while maintaining consistent medium properties and quality. Consequently, it is an ideal choice for processing industries such as cosmetics, petroleum, biopharmaceuticals, brewing, and food.

Product Details:

3RP series rotary lobe pumps consist of two synchronously counter-rotating three-lobe spiral rotors, forming sealed chambers between the rotors and the pump casing. As the rotors rotate, material is drawn into the chambers and transported to the discharge end with the rotor rotation. Due to the rotors' unique design, the chamber volume remains constant during conveyance, enabling smooth, pulsation-free material transfer. Simultaneously, the minimal clearance between the rotors and pump housing effectively prevents backflow, ensuring high delivery efficiency.

Application:

1. Pharmaceutical Industry: Suitable for transporting pharmaceutical solutions, syrups, ointments, suppositories, and other medications, complying with GMP regulations to guarantee drug quality.
2. Personal Care Industry: Used for transporting shampoo, body wash, toothpaste, cosmetics, detergents, and other personal care products, maintaining product stability and integrity.
3. Chemical Industry: Capable of conveying various acids, alkalis, salts, solvents, resins, coatings, paints, and other corrosive or high-viscosity chemicals with strong adaptability.
4. Food Industry: Used for conveying honey, syrups, jams, dairy products, condiments, alcoholic beverages, etc., meeting food-grade hygiene standards to ensure food safety.
5. Other Fields: Also applicable in petroleum, metallurgy, environmental protection, and other industries for conveying various special media.

Feature:

1. Ensures smooth, pulsation-free material conveyance, effectively reducing shear and compression forces to preserve the material's original properties.
2. Guarantees zero leakage when handling toxic, hazardous, flammable, explosive, or valuable materials, safeguarding production safety and environmental hygiene.
3. All flow-through components are constructed from wear-resistant and corrosion-resistant materials to ensure stable and efficient conveying under various harsh conditions.
4. Features outstanding self-priming capability with a lift height of 7-9 meters, eliminating the need for additional priming operations. This significantly simplifies startup procedures and enhances operational efficiency.

Performance Data:

Model	Flow		Pressure	Rev	Power	Inlet/outlet size
Model	(L/100r)	(m³/h)	(Mpa)	(rpm)	(kW)	(mm)
3RP-25	6	≤1.8	0-1.0	≤600	0.75	25
3RP-32	9	≤2.7	0-1.0		1.1	32
3RP-40	18	≤4.3	0.-1.0		1.5	40
3RP-50	36	≤8.6	0-1.0		2.2	50
3RP-65	60	≤14.4	0-1.0		4	65
3RP-80	105	≤25.2	0-1.0		11	80
3RP-100A	125	≤30	0-1.0		15	100
3RP-100	150	≤36	0-1.0		18.5	100
3RP-125	250	≤60	0-1.0		22	125
