Product Description

Summarize:

YCB series magnetic gear pump brings the design, production and use of gear pumps into a new realm. It is suitable for pumping non-corrosive lubricating oils or equivalent liquids with temperatures below 300°C, viscosities from 5-1500 cSt, and free of solid particles and fibers. The equipment provides a high performance, energy efficient and cost-effective solutions for the chemical, petroleum, construction and other industires.

Product Details:

YCB series gear oil pumps deliver liquid through the change of working volume between pump casing and meshing gears. When two gears mesh, the pump casing and front and rear covers form two closed cavities. As the gears rotate in a specific direction, the volume of the cavity on the side of the meshing gears changes from small to large, forming a vacuum to draw in the liquid, and the volume of the cavity on the side of the meshing gears changes from large to small, squeezing the liquid into the discharge pipe.

Application:

1. It can be also applied as fuel pump for delivery system, pressurization and injection in fuel supply system.
2. This pump can give performance as transfer pump or booster in oil deliver system.
3. As a hydraulic pump supplying hydraulic power in hydraulic system.
4. In all industry fields it can be as lubricating pump.

Feature:

1. They are bi-rotational so the discharge end can be changed.
2. The circular arc design of this machine allows for smooth and efficient oil delivery to improve overall productivity.
3. The pumps are use reliable materials and precision technology to ensure the high performance of the machine even under harsh working conditions.
4. With the YCB type gear pump of compact construction and durable materials, which reduces downtime and maintenance costs throughout the life of the unit.

Performance Data:

Model	Flow (m3/h)	Presure (Mpa)	Rev (r/min)	Npshr (m)	Frequency (hz)
Model	Flow (m3/h)	Presure (Mpa)	Rev (r/min)	Npshr (m)	Frequency (hz)
YCB0.6-0.6	0.6	0.6	910	5.5	50
	1		1390		50
	0.7		1130		60
	1.2		1710		60
YCB0.6-1.6	0.6	1.6	910	7	50
	1		1400		50
	0.7		1130		60
	1.2		1710		60
YCB1.6-0.6	1.6	0.6	910	5.5	50
	2.5		1400		50
	1.9		1130		60
	3		1710		60
YCB1.6-1.6	1.6	1.6	940	7	50
	2.5		1440		50
	1.9		1150		60
	3		1750		60
YCB3.3-0.6	3.3	0.6	940	5	50
	5		1420		50
	4		1150		60
	6		1730		60
YCB3.3-1.6	3.3	1.6	960	7	50
	5		1440		50
	4		1170		60
	6		1750		60
YCB4-0.6	4	0.6	940	5	50
	6		1420		50
	4.8		1150		60
	6		1730		60
YCB4-1.6	4	1.6	960	7	50
	6		1440		50
	4.8		1170		60
	7.2		1750		60
YCB8-0.6	8	0.6	960	5	50
	12		1440		50
	9.6		1170		60
	14.4		1750		60
YCB8-1.6	8	1.6	970	7	50
	12		1460		50
	9.6		1170		60
	14.4		1760		60
YCB10-0.6	10	0.6	960	5	50
	15		1440		50
	12		1170		60
	18		1750		60
YCB10-1.6	10	.1.6	970	7	50
	15		1470		50
	12		1170		60
	18		1770		60
