Product Description

Summarize:

KCB cast iron gear pump is an external gear pump featuring a compact structure, low noise, long service life, and simple maintenance. It is primarily used for handling non-corrosive lubricants with temperatures below 300°C and viscosities ranging from 5 to 1500 cst, including crude oil, diesel, heavy oil, vegetable oil, and lubricating oil. This equipment employs advanced gear design and precision manufacturing techniques to effectively reduce energy consumption during the pumping process, thereby enhancing overall pumping efficiency and extending its service life.

Product Details:

KCB series lubricating oil gear pumps primarily consist of gears, shafts, pump bodies, valves, and shaft end seals. During operation, internal components are automatically lubricated by the output medium. Moreover, to minimize the torque exerted on the gears during operation, this series employs a rational configuration of oil discharge and return tanks.

Application:

1. Petrochemical Industry: Asphalt, tar, diesel, crude oil, lubricating oil.
2. Chemical Industry: Sodium silicate, acids, plastics, mixed chemicals.
3. Food Industry: Chocolate, cocoa butter, fillers, sugars, vegetable oils, molasses.
4. Pulp and Paper Industry: Acids, soap solutions, alkali solutions, black liquor, kaolin, lime, latex, sludge.

Feature:

1. With outstanding self-priming capability, it achieves self-priming without external assistance, offering simple operation and making it particularly suitable for specific demanding work environments.
2. To ensure a quiet working environment during operation, we have optimized the gear meshing structure and incorporated vibration damping design, guaranteeing low-noise performance.
3. The pump body utilizes premium materials for both gears and casing, ensuring long-term stable performance and reducing the probability of failure.

Performance Data:

Model	Capacity Q		Speed	Exhaust pressure P	Motor
Model	m³/h	l/min	r/min	Mpa	Power Kw
KCB-18.3	1.1	18.3	1400	1.45	1.5
KCB-33.3	2	33.3	1420	1.45	2.2
KCB-55	3.3	55	1400	0.33	1.5
KCB-83.3	5	83.3	1420	0.33	2.2
KCB-135	8	135	940	0.33	2.2
KCB-200	12	200	1440	0.33	4
KCB-300	18	300	960	0.36	5.5
KCB-483.3	29	483.3	1440	0.36	7.5
KCB-633	38	633	970	0.28	11
KCB-960	58	960	1470	0.28	11
KCB-1200	72	1200	740	0.6	37
KCB-1600	96	1600	980	0.6	45
KCB-1800	110	1800	740	0.6	55
KCB-2500	150	2500	985	0.6	75
KCB-2850	170	2850	740	0.6	90
KCB-3800	230	3800	989	0.6	110
KCB-4100	245	4100	743	0.6	132
KCB-5400	325	5400	989	0.6	160
KCB-5600	330	5600	744	0.6	160
KCB-7600	460	7600	989	0.6	200
KCB-7000	420	7000	744	0.6	185
KCB-9600	570	9600	989	0.6	250
KCB-13000	800	13000	490	0.6	315
