Bulk Orders KCB-200 Cast Iron Lube Oil Gear Pump for Marine Industry

KCB Series Electric Gear Oil Transfer Pump

KCB 200 Gear Oil Pump

KCB series gear oil transfer pump constitutes a positive-displacement meshing gear pump specifically designed for the continuous delivery of oils and other lubricating fluids with similar flow characteristics. It provides stable fluid delivery for applications including lubricating oil circulation, crude oil transfer, fuel oil transfer, loading systems, industrial equipment lubrication, and boiler fuel supply. This series of pumps covers flow rates ranging from 1.1 m³/h to 800 m³/h, allowing for flexible configuration of pump specifications to match different pipeline capacities and operational requirements, helping production operations effectively improve efficiency and increase output.

Head Lift: 28-145m

Power: 1.5-350Kw

Flow Rate: 1.1-900m³/h

Send Email Chat Now

Share With:

Product Classification

Gear Pump

Centrifugal Pump

Rotary Lobe Pump

Screw Pump

LPG Gas Pump

Filling Machine

Self-Priming Pump

Diaphragm Pump

Vacuum Pump

Multistage Pump

Magnetic Pump

Chemical Pump

Application

Email: sales@shenghuipump.com

Fax: +86-0317-8109918

Tel: +86-0317- 8109958 +86-0317-8109968

Whatsapp & Wechat & Mobile:
+86-15227503158

Add: South 4 # Road, Industrial Park, Botou City , 062150, Hebei Province,China

G Series Sludge Screw Pump

ZX Self-Priming Centrifugal Pump

ISW Series Horizontal Inline Centrifugal Pump

ISW Series Inline Centrifugal Pump

LPG Gas Pump for Sale

Mineral Water Bottle Filling Machine

Product Description

Summarize:

KCB horizontal gear pump transfers liquid from the suction side to the discharge port by utilizing the sealed space formed between the meshing gears and the pump casing. This operating principle makes it applicable for applications involving high-viscosity fluids that require continuous, stable delivery, as well as those requiring reliable oil transfer and pressure boosting. Moreover, the gears of this equipment are fabricated from high-quality materials and undergo heat treatment processes such as quenching, which endows them with extremely high surface hardness and toughness. This effectively enhances the gear teeth’s wear resistance and impact resistance, satisfying conveying requirements under various operating conditions.

Product Details:

In KCB series gear oil pumps, the motor drives the drive gear to rotate, causing the driven gear to rotate in the opposite direction due to gear meshing, thereby drawing in fluid. As the gears continue to rotate, the clearance between them gradually decreases, and the pumped fluid reaches the discharge side and is pushed into the pipeline, ensuring a steady flow.

Application:

KCB oil pumps are applicable for conveying various common oil-based media that do not contain solid particles or fibers, such as lubricating oil, fuel oil, diesel, crude oil, and similar non-corrosive oil-based media. This includes applications such as oil transportation in the petrochemical industry, loading and unloading operations at oil terminals, combustion systems in metallurgical and mining operations, fuel supply for ships, and the transportation of edible oils in food processing.

Feature:

1. While in operation, the pump exhibits minimal vibration and runs smoothly, effectively reducing the wear rate of core components and extending the service life of the equipment.
2. The performance of this series of equipment does not decline significantly as fluid viscosity increases, making it suitable for continuous pumping applications.
3. It can typically be equipped with a safety valve to protect the pump and drive system from high discharge pressures.

Performance Data:

Model	Capacity Q		Speed	Exhaust Pressure	Motor Power
Model	m³/h	l/min	r/min	Mpa	Kw
KCB-18.3	1.1	18.3	1400	1.45	1.5
KCB-33.3	2	33.3	1420	1.45	2.2
KCB-55	3.3	55	1400	0.33	1.5
KCB-83.3	5	83.3	1420	0.33	2.2
KCB-135	8	135	940	0.33	2.2
KCB-200	12	200	1440	0.33	4
KCB-300	18	300	960	0.36	5.5
KCB-483.3	29	483.3	1440	0.36	7.5
KCB-633	38	633	970	0.28	11
KCB-960	58	960	1470	0.28	11
KCB-1200	72	1200	740	0.6	37
KCB-1600	96	1600	980	0.6	45
KCB-1800	110	1800	740	0.6	55
KCB-2500	150	2500	985	0.6	75
KCB-2850	170	2850	740	0.6	90
KCB-3800	230	3800	989	0.6	110
KCB-4100	245	4100	743	0.6	132
KCB-5400	325	5400	989	0.6	160
KCB-5600	330	5600	744	0.6	160
KCB-7600	460	7600	989	0.6	200
KCB-7000	420	7000	744	0.6	185
KCB-9600	570	9600	989	0.6	250
KCB-13000	800	13000	490	0.6	315
