Automatic liquid bottle filling machine is mainly used for filling, feeding and capping of glass or plastic bottles. It is often used in food, cosmetics, medicine, daily chemical industry, pesticide and chemical industry. The machine has high degree of automation, reasonable machine design, convenient operation features, including the machine has no bottle without filling, no bottle without capping, no cap without capping and other functions.
Product Details:
When using this product, you need to go through the process of transportation, filling, cleaning, sealing and capping. The machine can be easily applied to many different shapes of bottles, greatly reducing the inconvenience of auxiliary equipment and filling. Automatic liquid filling machine adopts advanced technology, which can precisely control the filling volume and filling speed through PLC control system. The material can be conveyed to the filling head through the pipeline, and the filling head will be filled according to the set parameters, which can realize high-precision quantitative filling.
Application:
1. Food Industry: This machine is mainly used for liquids such as beverages, mineral water, fruit juices, energy drinks, edible oils, honey and cream.
2. Dairy Industry: It caters to the filling needs of dairy products such as milk, flavored milk, whipped cream and yogurt.
3. Daily chemical Industry: Can fill lotion, shampoo, shower gel, flower water, perfume and other liquids.
4. Pharmaceutical Industry: It can fill oral liquid, syrup, injectable drugs, eye drops and so on.
Feature:
1. Adopting advanced sensors and control system, the filling precision is high to ensure the accuracy of filling quantity.
2. The whole machine adopts PLC control, which is simple and convenient to operate, and can realize the functions of automatic filling, automatic measuring, automatic sealing, etc., which reduces the manual intervention and improves the production efficiency.
3. The part contacting with materials is made of high quality stainless steel, which meets the requirements of food hygiene and pharmaceutical production, and also adopts the design of anti-dripping and anti-pulling to avoid material waste and environmental pollution.
Performance Data:
| Model |
RCGF14-12-5 |
RCGF16-16-5 |
RCGF24-24-8 |
RCGF32-32-8 |
RCGF40-40-12 |
RGF60-60-15 |
| Capacity(for 500ml) |
2000BPH |
4000BPH |
8000-10000BPH |
12000-15000BPH |
16000-18000BPH |
24000BPH |
| Suitable Bottle Shapes |
circular or square |
| Bottle Diameter(mm) |
Dia50-Dia115mm |
| Bottle Height (mm) |
160-320mm |
| Filling Type |
Overflow filinig type /Hot filling |
| Function |
Rinsing filling capping |
| Rinsing Pressure |
>0.06Mpa <0.2Mpa |
| Application |
Juice / Tea drinks / Milk Beverage |
| Total Power (KW) |
4.4kw |
4.4kw |
4.4kw |
5.2kw |
6.2kw |
7.8kw |
| Overall Dimensions |
2.3*1.9m |
2.5*1.9m |
2.8*2.15m |
3.1*2.5m |
3.8*2.8m |
4.5*3.3m |
| Height |
2.3m |
2.5m |
2.5m |
2.5m |
2.5m |
2.6m |
| Weight(kg) |
3500kg |
5200kg |
7000kg |
9500kg |
10500kg |
12000kg |
