Product Description

Summarize:

Automatic pouch bag in box filling machine is specially designed for handling quantitative bag-in-box filling operation, which can automatically complete the process of opening the cap, quantitative filling, vacuum pumping, capping and so on. It can be widely used for bag-in-box filling of liquor, edible oil, fruit juice, additives, milk, syrup, alcoholic beverages, concentrated seasoning and other liquid materials. The product adopts the advanced flow system to automatically control the amount of material discharged each time, with high filling precision and consistent filling volume.

Product Details:

Using the automatic pouch packing machine, the boxes and bags to be filled must be placed in the filling position and secured by the positioning mechanism to ensure they remain stable and do not move. The filling head is then lowered and precisely inserted into the bag opening, injecting the material into the bag according to the pre-set quantity. During the filling process, the machine continuously monitors the material flow rate and liquid level to ensure that each bag is filled with an appropriate and consistent amount of material, preventing overflow due to overfilling or waste/underfilling due to insufficient filling.

Application:

1. Juice: It can be used for aseptic filling of various fruit juices and concentrated fruit juices, such as apple juice, orange juice, grape juice, etc., which can effectively retain the nutrients and fresh taste of fruit juice.
2. Dairy products: It is suitable for milk, yogurt, cream and other products filling, to ensure product sterility and quality stability, to extend the shelf life of the product.
3. Tea drinks: Used for filling tea drinks, to ensure that the product is not contaminated by microorganisms in the filling process.
4. Aseptic drugs: For the production of vaccines, antibiotic injections, biological preparations and other aseptic drugs.
5. Cosmetics: For the production of aseptic cosmetics, such as lotions, creams, serums, etc.

Feature:

1. Automatically complete the process of cap pulling, vacuuming, quantitative filling and capping at the same station, overcoming the problem of material overflow due to the movement of bag-in-box before capping after filling.
2. Pipes in contact with materials are made of stainless steel and food-grade secondary ah, CIP cleaning can be realized, in line with food hygiene requirements.
3. Adopting advanced metering system and intelligent touch screen interface system to ensure precise control of filling quantity.
4. The equipment can vacuum the bag before filling, which can reasonably extend the shelf life of the product.
5. Equipped with imported electronic and pneumatic components, durable and easy to operate.
6. It adopts modular design, easy to maintain and adjust.

Performance Data:

Filling Quantity Range	1L-30L
Filling Precision	99%
Filling Speed	220---240 bags/hour
Material Entrance Pressure	≤0.3-0.35 Mpa
Supply Voltage	AC220V/50Hz±10% voltages can be customized
