Product Description

Summarize:

With its carefully designed hydraulic structure, wide flow range, and high pumping efficiency, the IS centrifugal pump has become a popular choice in municipal water supply, high-rise building pressure boosting, industrial drainage, and agricultural irrigation. The pump generates centrifugal force through the high-speed rotation of the impeller, imparting kinetic energy to the fluid, which is then converted into pressure energy, resulting in continuous and stable fluid delivery. To extend the equipment’s maintenance intervals, materials are selected based on the characteristics of the fluid, and the design incorporates quenched gears that effectively maintain gear meshing even during prolonged operation, minimizing flow instability caused by wear.

Product Details:

When liquid enters the center of the impeller through the pump’s suction inlet, the liquid inside the impeller is subjected to centrifugal force as the impeller rotates at high speed, causing it to move from the center of the impeller toward its outer edge. The departure of liquid from the center of the impeller creates a low-pressure area at the suction inlet, allowing liquid to continue entering the pump chamber. Concurrently, some of the kinetic energy is converted into pressure energy, giving the liquid sufficient head, after which it enters the piping system through the discharge outlet. Through the continuous rotation of the impeller, a steady flow of liquid is established within the pump, thereby ensuring stable delivery.

Application:

IS series single stage centrifugal pumps are specialized equipment designed to pump clean water or other liquid media with physical and chemical properties similar to those of clean water. They find applications in industrial water supply, building drainage, recirculating cooling systems, agricultural irrigation, and general process fluid transfer.

Feature:

1. This series of equipment features excellent versatility, stable continuous flow capacity, and an internal structure designed for easy maintenance.
2. It delivers stable liquid flow without requiring complex, specialized designs, making it well-suited for applications involving potable-grade industrial water supply and recirculating water systems.
3. The pump’s open-design construction allows for inspection and maintenance by simply removing the relevant components, without the need to relocate the piping system or the pump housing.

Performance Data:

Model	Flow (m³/h)	Head (m)	Power (w)	Speed (r/m)
IS50-32-125	12.5	20	2.2	3000
IS50-32-160	12.5	32	3	3000
IS50-32-200	12.5	50	5.5	3000
IS50-32-250	12.5	80	11	3000
IS65-50-125	25	20	3	3000
IS65-50-160	25	32	5.5	3000
IS65-40-200	25	50	7.5	3000
IS65-40-250	25	80	15	3000
IS65-40-315	25	125	30	3000
IS80-65-125	50	20	5.5	3000
IS80-65-160	50	32	7.5	3000
IS80-50-200	50	50	15	3000
IS80-50-250	50	80	22	3000
IS80-50-315	50	125	37	3000
IS100-80-125	100	20	11	3000
IS100-80-160	100	32	15	3000
IS100-65-200	100	50	22	3000
IS100-65-250	100	80	37	3000
IS100-65-315	100	125	75	3000
IS100-65-315	100	125	11	1450
IS125-100-200	200	50	45	3000
IS125-100-250	200	80	75	3000
IS125-100-250	200	80	11	1450
IS125-100-315	200	125	110	3000
IS125-100-315	200	125	15	1450
IS125-100-400	100	50	30	1450
IS150-125-250	200	20	18.5	1450
IS150-125-315	200	32	30	1450
IS150-125-400	200	50	45	1450
IS200-150-250	400	20	37	1450
IS200-150-315	400	32	55	1450
IS200-150-400	400	50	90	1450
