Our company has developed and produced 2W double screw pumps in accordance with the actual requirements of current oil and gas mixing. This product is capable of conveying all kinds of media from low viscosity to high viscosity, such as crude oil, fuel oil, heavy oil, lubricating oil, pigment, ink, latex, milk, syrup and fruit juice. 2W series industrial screw pump adopts double suction structure, both ends of the screw are in the same pressure chamber, the axial force can be self-balancing, thus reducing the impact of axial force on the pump and improving the stability of pump operation. In order to convey all kinds of non-lubricating media, our two-end bearings adopt external design and lubricate with separate lubricant, which is also convenient for maintenance and bearing replacement. At the same time, the two screws are driven by the same pair of synchronized gears, and there is no contact between the teeth of the screws to leave a small gap, so that impurities in the medium will not directly wear on the teeth of the screws. In other words, the product can be idled for a short period of time without any harm, and this design can prolong the service life of the screw.
2W series oil screw pump conveys liquid smoothly, no pulsation, no agitation, low vibration, low noise and other characteristics, can effectively reduce the disturbance of the conveying medium and noise pollution of the working environment. The product also has a strong self-priming ability, in the multi-phase mixed transport, gas content of gas rate is not higher than 80%, the sand content is not higher than 500g/m³, so it is more suitable for a variety of complex conveying conditions.2W series of screw pumps can reach a maximum working pressure of 4.0MPa, the flow rate range of 1-1000m³/h, the temperature range of the media can be in the range of -20-120 ℃. If you need detailed product information, you can contact our staff for you. 2W series twin screw pumps can be used as oil, gas, water, trace fine solid particles and other multi-phase mixing pumps and crude oil transfer pumps in the oilfield industry. It can also be used as marine loading pumps, bilge sweeping and sewage treatment and other fields. If you want to transport all kinds of clean or contain solid small particles of low-viscosity or high-viscosity media, the product of the pump body can be equipped with a heating jacket.
